3-9
3 Assigning Device Variables for CJ-series Units
CJ-series EtherNet/IP Units Operation Manual for NJ-series CPU Unit (W495)
3-2 Device Variables for the CJ-series Unit
3
3-2-3 Device Variables for the CJ-series Unit for Status
This variable gives the status of the EtherNet/IP Unit.
Unit Status 1 (EtherNet/IP Unit to CPU Unit) (*_UnitSta1)
Unit Status Information
Device variable name for CJ-
series Unit
Data
type
R/W Meaning Description
*_UnitSta1 WORD R Unit Status 1 Bit 00: Unit Error
Bit 01: Network Error
Bit 04: Unit Memory Error
Bit 05: Communications Controller Error
Bit 06: IP Address Duplication
Bit 09: Link OFF Error
Bit 14: Status Area Layout Setting Error
*_UnitErr BOOL R Unit Error Occurred TRUE: An error occurred in the operation of the
EtherNet/IP Unit.
This variable changes to TRUE when any of
the following variables in Unit Status 1
changes to TRUE. (That is, it is an OR of the
status of the following variables.)
*_NetEr
*_UnitMemErr
*_LANHwErr
*_IPAdrDupErr
*_LkOffErr
*_UserStaAreaCfgErr
FALSE: None of the above errors currently exists.
(If any of the errors did occur, it has been
cleared.)
Default: FALSE
*_NetErr BOOL R Network Error
Occurred
TRUE: There is one or more network-related errors.
(This is an OR of the Communications Sta-
tus 1 and 3 variables. )
FALSE: None of the above errors currently exists. (If
any of the errors did occur, it has been
cleared.)
Default: FALSE
*_UnitMemErr BOOL R Unit Memory Error TRUE: An error occurred in accessing the Unit's
internal non-volatile memory (device error).
FALSE: A non-volatile memory error has not
occurred. Once this error occurs, it is not
cleared. (The variable remains TRUE.)
Default: FALSE
*_LANHwErr BOOL R Communications
Controller Error
TRUE: An error occurred in the communications
controller.
FALSE: A communications controller error has not
occurred. This variable remains TRUE until
the power supply is cycled.
Default: FALSE
To Next Page
