Omron CS1W User Manual

Specifications
12
Connection Configurations
The following table shows the connection configurations that can be used to connect an
OMRON PLC (or PT) to a personal computer's USB port.
USB-Serial
Conversion
Cable
Conversion
Cable's serial
connector
Required adapters or cables Compatible
PLC or PT
connector
Compatible PLCs
and PTs
•CS1W-CN226/626
(Programming Device Connecting Cable for a
CS/CJ-series peripheral port and personal
computer)
•XW2Z-200/500S-CV or XW2Z-200/500S-V
(Programming Device Connecting Cable for
an RS-232C port and personal computer)
+
•CS1W-CN118
(RS-232C to CS/CJ-series peripheral port
Conversion Cable)
•CQM1-CIF02
(Programming Device Connecting Cable for a
C-series peripheral port and personal
computer)
+
•CS1W-CN114
(C-series peripheral port to CS/CJ-series
peripheral port Conversion Cable)
CS/CJ-series
peripheral
port
CS/CJ-series,
CQM1H, and
CPM2C
•CQM1-CIF02
(Programming Device Connecting Cable for a
C-series peripheral port and personal
computer)
C-series
peripheral
port
C200HS,
C200HX/HG/HE,
CQM1, CPM1,
CPM1A, CPM2A,
and SRM1
•RS-232C 9-pin to 25-pin adapter
+
•CV500-CIF01
(Programming Device Connecting Cable for a
CV-series peripheral port and PC98-type
personal computer)
CV-series
peripheral
port
CVM1/CV-series
•XW2Z-200/500S-CV or XW2Z-200/500S-V
(Programming Device Connecting Cable for
an RS-232C port and personal computer)
RS-232C port
(D-sub 9-pin)
PLCs (CPU Unit
or Serial
Communication
Unit/Board
connection) or
PTs
CS1W-CIF31
(D-sub version)
D-sub 9-pin
male
ZEN-CIF01
(Personal Computer Connecting Cable)
Personal
Computer
Connecting
port
ZEN
Note The USB-Serial Conversion Cables are for connections between a USB port and an
OMRON PLC/PT only. In particular, the CS1W-CIF31 Cable can be used only with
compatible OMRON software applications even though it has a standard D-sub 9-pin
connector on one end.
