USB to PLC/PT Connection Tables
22
USB to PLC/PT Connection Tables
Connecting with the CS1W-CIF31 (D-sub Connector Cable)
Computer CS1W-CIF31 Cable 1
Cable 2
(when necessary)
PLC
CS1W-CIF31 USB
Conversion Cable
+
OR
OR
CS1
W
-CN226/626 Programming
Device Connecting Cable for a
CS/CJ-series peripheral port
XW2Z-@@@ Programming Device
Connecting Cable for RS-232C
CQM1-CIF02 Programming
Device Connecting Cable for a
C-series peripheral port
+
CS1W-CN118
RS-232C to CS/CJ-series peripheral
port Conversion Cable
CS1W-CN114
C-series peripheral port to CS/CJ-series
peripheral port Conversion Cable
█ CS/CJ-series Units
● CS/CJ-series CPU Units
USB
Conversion
Cable
Cable 1 Cable 2 Unit's port Serial
communications
mode
Model Connector Model Connector Connector Model Connector (Network type)
D-sub 9-pin,
female
CS1W-CN226/626
(Length: 2 or 6 m)
CS/CJ-series
peripheral
Not necessary Peripheral bus
(Toolbus) or Host
link (SYSWAY)
D-sub 9-pin,
female
CQM1-CIF02
(Length: 3.3 m)
C-series
peripheral
C-series
peripheral
CS1W-CN114
(Length: 5 cm)
CS/CJ-series
peripheral
Host link
(SYSWAY)
D-sub 9-pin,
female
XW2Z-200S-CV
/500S-CV
(Length: 2 or 5 m)
D-sub 9-pin,
male
D-sub 9-pin,
female
CS1W-CN118
(Length: 0.1 m)
CS/CJ-series
peripheral
Peripheral bus
(Toolbus) or Host
link (SYSWAY)
D-sub 9-pin,
female
XW2Z-200S-V
/500S-V
(Length: 2 or 5 m)
D-sub 9-pin,
male
D-sub 9-pin,
female
CS1W-CN118
(Length: 0.1 m)
CS/CJ-series
peripheral
CS/CJ-series
peripheral
Host link
(SYSWAY)
D-sub 9-pin,
female
XW2Z-200S-CV
/500S-CV
(Length: 2 or 5 m)
RS-232C
D-sub 9-pin,
male
Not necessary Peripheral bus
(Toolbus) or Host
link (SYSWAY)
CS1W-CIF31
D-sub 9-pin,
female
XW2Z-200S-V
/500S-V
(Length: 2 or 5 m)
RS-232C
D-sub 9-pin,
male
Not necessary
RS-232C
D-sub 9-pin,
female
Host link
(SYSWAY)
