Omron CS1W - CVM1;CV-series, PTs, and ZEN Relay Connections

USB to PLC/PT Connection Tables
25
● C-series Host Link Unit (C200H-LK201-V1 or C120-LK201-V1)
Note: The Host Link Unit cannot be used to connect a Programming Device (such as the
CX-Programmer) to a C200HX/HG/HE with the "-ZE" suffix at the end of the model number.
USB
Conversion
Cable
Cable 1 Cable 2 Unit's port Serial
communications
mode
Model Connector Model Connector Connector Model Connector (Network type)
CS1W-CIF31 D-sub 9-pin,
female
XW2Z-200P-V
/500P-V
(Length: 2 or 5 m)
D-sub 25-pin,
male
Not necessary RS-232C
D-sub
25-pin,
female
Host link
(SYSWAY)
● C-series Communications Board (C200HX/HG/HE PLCs Only)
USB
Conversion
Cable
Cable 1 Cable 2 Unit's port Serial
communications
mode
Model Connector Model Connector Connector Model Connector (Network type)
D-sub 9-pin,
female
XW2Z-200S-CV
/500S-CV
(Length: 2 or 5 m)
D-sub 9-pin,
male
Not necessary Host link
(SYSWAY)
CS1W-CIF31
D-sub 9-pin,
female
XW2Z-200S-V
/500S-V
(Length: 2 or 5 m)
D-sub 9-pin,
male
Not necessary
RS-232C
D-sub
9-pin,
female
● C200H, C1000H, and C2000H Host Link Units
Note: The C500-LK203 and C500-LK 201-V1 Host Link Units can be used with the C1000H and
C2000H. The C200H-LK201-V1 and C120-LK201-V1 Host Link Units can be used with the
C200H.
USB
Conversion
Cable
Cable 1 Cable 2 Unit's port Serial
communications
mode
Model Connector Model Connector Connector Model Connector (Network type)
CS1W-CIF31 D-sub 9-pin,
female
XW2Z-200P-V
/500P-V
(Length: 2 or 5 m)
D-sub 25-pin,
male
Not necessary RS-232C
D-sub
25-pin,
female
Host link
(SYSWAY)
● CQM1H Serial Communication Board
USB
Conversion
Cable
Cable 1 Cable 2 Unit's port Serial
communications
mode
Model Connector Model Connector Connector Model Connector (Network type)
D-sub 9-pin,
female
XW2Z-200S-CV
/500S-CV
(Length: 2 or 5 m)
D-sub 9-pin,
male
Not necessary Host link
(SYSWAY)
CS1W-CIF31
D-sub 9-pin,
female
XW2Z-200S-V
/500S-V
(Length: 2 or 5 m)
D-sub 9-pin,
male
Not necessary
RS-232C
D-sub
9-pin,
female
