Omron E2C - Socket Mounting and Panel Cutouts; P3 GA-11 Socket Details

E2C
E2C
20
Back-connecting Socket
Front View
P3GA-11
Terminal Arrangement
27 dia.
P3G-08
Terminal Arrangement
Mounting Dimensions
Embedding Adapter
Y92F-30 (l = 45)
Y92F-71 (l = 55)
Two, 4.5-dia. adapter mounting holes
R0.5 max.
65 to 66
52 to 53
Embedding Adapter
Y92F-70
(Front view)
27 dia.
PY08
Terminal Arrangement
Panel Cutout
Eight 3 x 1.2 elliptic holes(see note)
42 max.
20 max.
24 max.
25.5 max.
29.5 max.
Eight 3 x 1.2 elliptic holes
Note:
Model PY08-1 includes the dimensions shown in dotted lines.
(Bottom view)
PL11
Mounting Holes
51 max.
35 max.
Approx. 20.5
Two 2 dia. holes
30 dia.
Two 3.5 dia. or two M3
socket-mounting holes
31 dia.
hole
