Omron E2C - Socket Mounting Options; PL08 Socket Details

E2C
E2C
21
PL08
Terminal Arrangement
Mounting Holes
(Bottom view)
Two 3.5 dia. or two M3
socket-mounting holes
31 dia.
hole
50.5 max.
35 max. Approx. 20.5
Two 2 dia. holes
30 dia.
PYF08M
40 max.
3.5 dia. mounting hole
6.5 dia. spot facing
Depth: 11.5
44.5 max.
18 max.
3dia.
M3.5 sems are used for terminal screws.
3.5 dia. hole
3.5dia.holeorM3
Mounting Fixture
Plastic Mounting Fixtures are available as options.
Select one suited to the dimensions of the Sensor.
Y92E-B
j
Adapter for Flush Mounting
Panel Cutout
Note:
Recommended panel thickness is
1 to 3.2 mm.
Panel
P3GA-11
Rear Connecting Socket
R0.5 max.
Y92F-30
