Omron E5 J Series User Manual

E5jJ
E5jJ
100 to 240 VAC 50 or 60 Hz
or
24 VAC 50 or 60 Hz
24 VDC
100 to 240 VAC 50 or 60 Hz
or
24 VAC 50 or 60 Hz
24 VDC
12 VDC 20 mA 4 to 20 mA
+
–
10
9
10
9
10
9
For relay
output
For voltage
output
For linear
output
+
–
Control output
Use these terminals
when connecting a
thermocouple.
5
4
3
1
14
13
12
11
–
+
Alarm
output 1
8
7
6
B
B
10
9
8
7
6
Alarm output 2
A
Use these terminals when con-
necting a platinum resistance
thermometer.
2
12 VDC 20 mA 4 to 20 mA
+
–
10
9
10
9
10
9
For relay
output
For voltage
output
For linear
output
+
–
Control output
Use these terminals
when connecting a
thermocouple.
5
4
3
2
1
14
13
12
11
–
+
8
7
6
B
B
10
9
8
7
6
A
Use these terminals when con-
necting a platinum resistance
thermometer.
E5CJ-j2 Simple Models
E5CJ-j Simple Models
SOURCE
SOURCE
Note: Always turn on the Controller and the load simultaneously . Never turn on the load when the Controller is already turned on. Doing so will
disable proper self-tuning and optimum control.
For example, when setting the parameters to the Controller with the load turned of f, turn of f the Controller once after completing the
setting and then turn it on again simultaneously with the load. Or , switch event input 2 from ST OP to RUN.
*
The alarm output 1 and heater burnout alarm are integrated into one general alarm.
* The event input is not electrically isolated from the voltage output or current output.
