E5jJ
E5jJ
SSR
Connection Example of Temperature Controller and SSR
+
–
+
–
Temperature Controller
Voltage output
terminal (for driv-
ing SSR)
Connectable
Load
Heater
Power supply
for load
Power SSR
SSR
E5AJ/E5BJ/E5EJ
Temperature Controller
with Voltage Output
(12 VDC, 40 mA max.)
See the following table.
E5CJ
Temperature Controller
with Voltage Output
(12 VDC, 20 mA max.)
INPUT LOAD
Model G3PA-VD
240
V
: 10 A, 20 A, 40 A, 60 A
480 V
: 20 A, 30 A
G3NH
75 A, 150 A
G3NA
240 V
: 5 A, 10 A, 20 A, 40 A
480 V
: 10 A, 20 A, 40 A
G3NE
5 A, 10 A, 20 A
G3B
5 A
Appearance
SSRs
connected
in
parallel
E5AJ/BJ/EJ: 5 pcs. (8 pcs.)
E5CJ: 3 pcs. (4 pcs.)
(see note)
E5AJ/BJ/EJ:
8 pcs.
E5CJ: 4 pcs.
E5AJ/BJ/EJ: 6 pcs.
E5CJ: 3 pcs.
E5AJ/BJ/EJ:
2 pcs.
E5CJ: 1 piece
E5AJ/BJ/EJ:
5 pcs.
E5CJ: 2 pcs.
Rated input
voltage
5 to 24 VDC 5 to 24 VDC 5 to 24 VDC
12 VDC
5 to 24 VDC
Features
Thin, monoblock
construction with heat sink
For high-power
heater control
Standard model with screw
terminals
Compact, low-cost
model with tab
terminals
Socket, model
with 5-A
switching
capacity
Note:
The number of Units in parentheses is for the 400-V type.
