101
Operation Level Section 5-3
This parameter measures the heater current from the CT input used for
detecting SSR short-circuits.
The heater current is measured and the leakage current 1 monitor is dis-
played.
• HS are not detected if the control output (heating) OFF time is 190 ms or
less.
• ffff is displayed when 55.0 A is exceeded.
• If an SSR short-circuit is detected, the HA indicator will light, and the rela-
tive setting level will flash on the No. 1 display.
Related Parameters
HS alarm 1(adjustment level): Page 110
HS alarm use (advanced function setting level): Page 143
Error Displays lcr1
: Page 156
This parameter starts and stops the control operation.
When run (RUN) is selected, control is started. When stop (STOP) is
selected, control is stopped. The STOP indicator will light when control.
The default is run.
This parameter will not be displayed if an event input is set to “RUN/STOP.”
This parameter is set to one of the input values “X” in the alarm type list.
• This parameter sets the alarm value for alarm output 1.
lcr1 Leakage Current 1 Monitor
Heater burnout and HS alarms must
be supported.
Alarm 1 must be assigned.
The “HS alarm use” parameter must
be set to ON.
Monitor range Unit
0.0 to 55.0 A
Function
Monitor
See
See
r-s RUN/STOP
The run/stop function must not be set
for the “event input assignment 1/2”
parameter.
Function
See
See
al-1 Alarm Value 1
Alarm 1 must be assigned.
The “alarm 1 type” parameter must
not be set to an upper/lower limit
alarm and a loop break alarm must
not be set.
Function
■
To Next Page
