102
Operation Level Section 5-3
During temperature input, the decimal point position depends on the cur-
rently selected sensor, and during analog input it depends on the “deci-
mal point” parameter setting.
Related Parameters
Input type: Page 119, Scaling upper limit, Scaling lower limit, Decimal point
(initial setting level): Page 121
Alarm 1 type (initial setting level): Page 124
Standby sequence reset: Page 133, Alarm 1 o
pen in alarm: Page 134, Alarm
1 hysteresis: Page 135, Alarm 1 latch:
Page 139 (advanced function setting
level)
This parameter is set to one of the input values “X” in the alarm type list.
This parameter sets the alarm value for alarm output 2.
During temperature input, the decimal point position depends on the cur-
rently selected sensor, and during analog input it depends on the “deci-
mal point” parameter setting.
Related Parameters
Input type: Page 119, Scaling upper limit, Scaling lower limit, Decimal point
(initial setting level): Page 121
Alarm 2 type (initial setting level): Page 126
Standby sequence reset: Page 133, Alarm 2 o
pen in alarm: Page 134, Alarm
2 hysteresis: Page 135, Alarm 2 latch:
Page 139 (advanced function setting
level)
This parameter is set to one of the input values “X” in the alarm type list.
This parameter sets the alarm value for alarm output 3.
Setting range Unit Default
1999 to 9999 EU 0
See
See
al-2 Alarm Value 2
Alarm 2 must be assigned.
The alarm 2 type must be set to
other than an upper and lower limit
alarm.
Setting range Unit Default
1999 to 9999 EU 0
Function
Setting
See
See
al-3 Alarm Value 3
Alarm 3 must be assigned.
The alarm 3 type must be set to
other than an upper and lower limit
alarm.
Function
Setting
Setting
