Omron E5 Z Series User Manual

103
Operation Level Section 5-3
• During temperature input, the decimal point position depends on the cur-
rently selected sensor, and during analog input it depends on the “deci-
mal point” parameter setting.
Related Parameters
Input type: Page 119, Scaling upper limit, Scaling lower limit, Decimal point
(initial setting level): Page 121
Alarm 3 type (initial setting level): Page 126
Standby sequence reset: Page 133, Alarm 3 o
pen in alarm: Page 134, Alarm
3 hysteresis: Page 135, Alarm 3 latch:
Page 139 (advanced function setting
level)
These parameters independently set the alarm value upper and lower limits
when the mode for setting the upper and lower limits is selected for the “alarm
1 type” parameter (initial setting level).
• This parameter sets the upper and lower limit values of alarm 1.
• During temperature input, the decimal point position depends on the cur-
rently selected sensor, and during analog input it depends on the “deci-
mal point” parameter setting.
Related Parameters
Input type: Page 119, Scaling upper limit, Scaling lower limit, Decimal point:
Page 121, Alarm 1 type: Page 124 (initial setting level), Standby sequence
r
eset: Page 133, Alarm 1 open in alar
m: Page 134, Alarm 1 hysteresis: Page
135, Alarm 1 latch: Page 139
(advanced function setting level).
These parameters independently set the alarm value upper and lower limits
when the mode for setting the upper and lower limits is selected for the “alarm
2 type” parameter (initial setting level).
• This parameter sets the upper and lower limit values of alarm 2.
Setting range Unit Default
−1999 to 9999 EU 0
See
See
al1h Alarm Value Upper Limit 1
Alarm 1 must be assigned.
Alarm 1 type must be set to upper
and lower limits, upper and lower
limit range, or upper- and lower-limit
with standby sequence.
al1l Alarm Value Lower Limit 1
Setting range Unit Default
−1999 to 9999 EU 0
Function
Setting
See
See
al2h Alarm Value Upper Limit 2
Alarm 2 must be assigned.
Alarm 2 type must be set to upper
and lower limits, upper and lower
limit range, or upper- and lower-limit
alarm with standby sequence.
al2l Alarm Value Lower Limit 2
Function
■
■
