Omron E5 Z Series User Manual

123
Initial Setting Level Section 5-6
Related Parameters
AT execute/cancel: Page 108, Manual reset value, Hysteresis (heating), and
Hysteresis (cooling): Page 114 (adjustment level)
ST sta
ble range (advanced function setting level): Page 137
• This parameter selects standard control or heating/cooling control.
• With the E5CZ and E5CZ-U, when heating/cooling control is selected,
alarm output 2 terminal (ALM2) is used as a control output (cooling), so
alarm 2 cannot be used.
• With the E5AZ and E5EZ, when heating/cooling control is selected, alarm
output 3 terminal (ALM3) is used as a control output (cooling), so alarm 3
cannot be used.
Related Parameters
MV monitor (heating): Page 104, MV monitor (cooling): Page 105 (operation
level)
Cooling coefficient: Page 113, Dead band, Hysteresis (heating), Hysteresis
(
cooling): Page 114 (adjustment level)
Con
trol period (heating), Control period (cooling) (initial setting level): Page
124
Control output 1 assignment: Page 146, Alarm outpu
t 1 assignment: Page
146, Alarm o
utput 2 assignment: Page 147, Alarm output 3 assignment:
Page 148
(advanced function setting level)
• The ST (self-tuning) function executes tuning from the start of program
execution to calculate PID constants matched to the control target. When
the ST function is in operation, be sure to turn ON the power supply of the
load connected to the control output simultaneously with or before starting
Controller operation.
• Auto-tuning can be started during self-tuning.
See
See
s-hc Standard or Heating/Cooling
Setting range Default
stnd: Standard, h-c: Heating/cooling stnd
Function
Setting
See
See
st ST (self-tuning)
The control must be set to a temper-
ature input, standard control, and 2-
PID control.
Parameter Setting range Unit Default
ST off: ST function OFF, on: ST
function ON
None on
Function
Setting
■
■
