124
Initial Setting Level Section 5-6
Related Parameters
Input type: Page 119, PID ON/OFF: Page 122 (initial setting level), ST stable
range (advanced function setting level): Page 137
• These parameters set the output periods. Set the control periods taking
the control characteristics and the electrical durability of the relay into
consideration.
• For standard control, use the “control period (heating)” parameter. The
“control period (cooling)” parameter cannot be used.
• Whenever the heating control output is a current output, the “control
period (heating)” parameter cannot be used.
• For heating/cooling control, the control period can be set independently
for heating and cooling. The “control period (heating)” parameter is used
for the heating control output, and the “control period (cooling)” parameter
is used for the cooling control output.
Related Parameters
PID ON/OFF (initial setting level): Page 122
• “Direct operation” refers to control where the manipulated variable is
increased when the process value increases. Alternatively, “reverse oper-
ation” refers to control where the manipulated variable is increased when
the process value decreases.
• Select one of the following three alarm 1 types:
Deviation, Deviation range, or Absolute value
See
See
cp Control Period (Heating)
The cooling control output and heat-
ing control output must be assigned
to relay/voltage outputs.
The control must be set to 2-PID
control.
For the “control period (cooling)”
parameter, the control must be set to
heating/cooling control.
c-cp Control Period (Cooling)
Parameters Setting range Unit Default
Control period (heating) 0.5 or 1 to 99 Second 20
Control period (cooling) 0.5 or 1 to 99 Second 20
Function
Setting
See
See
orev Direct/Reverse Operation
Setting range Default
or-r: Reverse operation, or-d: Direct operation or-r
Function
Setting
alt1 Alarm 1 Type
Alarm 1 must be assigned.
Function
■
■
