Omron E5 Z Series User Manual

134
Advanced Function Setting Level Section 5-7
• This parameter sets the output status for alarm 1.
• When “close in alarm” is set, the status of the alarm output function will be
output as is. When “open in alarm” is set, the status of the alarm output
function will be reversed before being output. The following table shows
the relationship between alarm output functions, alarm output and output
LCDs.
• When “open in alarm” is set, the “open in alarm” status is also applied to
heater burnout and HS alarm outputs, and to input error outputs.
Related Parameters
Alarm value 1: Page 101, Alarm value upper limit 1, Alarm value lower limit 1:
Page 103 (operation level)
Ala
rm 1 type (initial setting level): Page 124
Standby sequence reset: Page 133, Alarm 1 hysteresis: Page 135, Alarm 1
lat
ch: Page 139
(advanced function setting level)
• These parameters set the output status for alarm 2 and alarm 3 settings.
• When “close in alarm” is set, the status of the alarm output function will be
output as is. When “open in alarm” is set, the status of the alarm output
function will be reversed before being output. The following table shows
the relationship between alarm output functions, alarm output and output
LCDs.
al1n Alarm 1 Open in Alarm
Alarm 1 must be assigned.
Alarm output operation Alarm output Output LCDs
Close in alarm ON ON Lit
OFF OFF Not lit
Open in alarm ON OFF Lit
OFF ON Not lit
Setting range Default
n-o: Close in alarm, n-c: Open in alarm n-o
Setting
Function
See
See
al2n Alarm 2 Open in Alarm
Alarm 2 must be assigned.
al3n Alarm 3 Open in Alarm
Alarm 3 must be assigned.
Alarm output operation Alarm output Output LCDs
Close in alarm ON ON Lit
OFF OFF Not lit
Open in alarm ON OFF Lit
OFF ON Not lit
Setting range Default
n-o: Close in alarm, n-c: Open in alarm n-o
Function
Setting
■
