Omron E5 Z Series User Manual

169
Appendix A
Automatic Display
return Time
ret OFF or 1 to 99 off, 1 to
99
OFF Second
Alarm 1 Latch a1lt OFF, ON off, on OFF None
Alarm 2 Latch a2lt OFF, ON off, on OFF None
Alarm 3 Latch a3lt OFF, ON off, on OFF None
Move to Protect
Level Time
prlt 1 to 30 3 Second
Input Error Output sero OFF, ON off, on OFF None
Cold Junction Com-
pensation Method
cjc OFF, ON off, on ON None
MB Command Logic
Switching
rlrv OFF, ON off, on OFF None
Alarm 1 ON Delay a1on 0 to 999 (0: ON delay dis-
abled)
0 Second
Alarm 2 ON Delay a2on 0 to 999 (0: ON delay dis-
abled)
0 Second
Alarm 3 ON Delay a3on 0 to 999 (0: ON delay dis-
abled)
0 Second
Alarm 1 OFF Delay a1of 0 to 999 (0: OFF delay dis-
abled)
0 Second
Alarm 2 OFF Delay a2of 0 to 999 (0: OFF delay dis-
abled)
0 Second
Alarm 3 OFF Delay a3of 0 to 999 (0: OFF delay dis-
abled)
0 Second
Input Shift Type istp INS1: Temperature input 1-
point shift
INS2: Temperature input 2-
point shift
ins1, ins2 INS1 None
Auto/Manual Select
Addition
amad OFF, ON off, on OF
F None
HS Alarm Use hsu OFF, ON off, on ON None
HS Alarm Latch hsl OFF, ON off, on OFF None
HS Alarm Hysteresis hsh 0.1 to 50.0 0.1 A
LBA Detection Time lba 0 to 9999 (0: LBA function dis-
abled)
0 Second
LBA Level lbal Universal-input: 0.1 to 999.9 8.0 °C or °F
(See note.)
Analog input: 0.01 to 99.99 10.00 %FS
LBA Band lbab Universal-input: 0.0 to 999.9 3.0 °C or °F
(See note.)
Analog input: 0.00 to 99.99 0.20 %FS
Parameters Characters Setting (monitor) value Display Default Unit Set value
Note Set “none” as the unit for Controllers with Analog Inputs.
