• On the E5AR, control output 1 (OUT1) outputs to terminals F5 and F6,
and control output 2 (OUT2) outputs to terminals F3 and F4.
• On the E5ER, control output 1 (OUT1) outputs to terminals C5 and C6,
and control output 2 (OUT2) outputs to terminals C3 and C4.
• On a multi-point input type, output takes place from control output 3
(OUT3) and control output 4 (OUT4).
• If terminals 5 and 6 are used for pulse voltage output, approximately 2 V
are output when the power is turned ON. (Load resistance: 10 k
Ω or less
for 10 ms)
• For linear current output, approximately 2 mA are output for 1 ms when
the power is turned ON.
• Control outputs that are not used for control can be used for transfer out-
put with the “control output/transfer output assignment” setting.
• Specifications for each output type are listed in the following table.
• The Position-proportional Models have relay outputs (250 VAC, 1 A).
Control output 1 (OUT1) is open output and control output 2 (OUT2) is
closed output.
• Relay output specifications are as follows:
250 VAC, 1 A (including inrush current)
Output type Specifications
Pulse voltage output Output voltage: 12 VDC+15%, –20% (PNP)
Maximum load current: 40 mA, with short-circuit
protection circuit
Linear current output 0 to 20 mA DC (resolution: approx. 54,000)
4 to 20 mA DC (resolution: approx. 43,000)
Load: 500 Ω
or less
−
