4-6
I/O Allocation Section 4-2
Remote I/O Com-
munications
Yes Yes 37 353 669 985 Input value 1 for input calibration ch
Yes Yes 38 354 670 986 Input correction 1 ch
Yes Yes 39 355 671 987 Input value 2 for input calibration ch
Yes Yes 40 356 672 988 Input correction 2 ch
Yes Yes 41 357 673 989 (Reserved) ch
Yes No 46 362 678 994 (Reserved) Common
Yes Yes 47 363 679 995 Disturbance gain ch
Yes Yes 48 364 680 996 Disturbance time constant ch
Yes Yes 49 365 681 997 Disturbance rectification constant ch
Yes Yes 50 366 682 998 Disturbance judgement width ch
Yes Yes 51 367 683 999 First order lag operation 1: Time constant Common
Yes Yes 52 368 684 1000 First order lag operation 2: Time constant Common
Yes Yes 53 369 685 1001 First order lag operation 3: Time constant Common
Yes Yes 54 370 686 1002 First order lag operation 4: Time constant Common
Yes Yes 55 371 687 1003 Move average 1: Number of measurement for
moving average
Common
Yes Yes 56 372 688 1004 Move average 2: Number of measurement for
moving average
Common
Yes Yes 57 373 689 1005 Move average 3: Number of measurement for
moving average
Common
Yes Yes 58 374 690 1006 Move average 4: Number of measurement for
moving average
Common
Yes Yes 59 375 691 1007 Extraction of square root operation 1: Low-cut
point
Common
Yes Yes 60 376 692 1008 Extraction of square root operation 2: Low-cut
point
Common
Yes Yes 61 377 693 1009 Extraction of square root operation 3: Low-cut
point
Common
Yes Yes 62 378 694 1010 Extraction of square root operation 4: Low-cut
point
Common
Yes Yes 63 379 695 1011 Analog parameter 1 (Control ratio) Common
Yes Yes 64 380 696 1012 (Reserved) Common
Yes Yes 65 381 697 1013 (Reserved) Common
Yes Yes 66 382 698 1014 (Reserved) Common
Yes Yes 67 383 699 1015 (Reserved) Common
Yes Yes 68 384 700 1016 (Reserved) Common
Yes Yes 69 385 701 1017 (Reserved) Common
Yes Yes 70 386 702 1018 (Reserved) Common
Yes Yes 71 387 703 1019 (Reserved) Common
Yes Yes 72 388 704 1020 (Reserved) Common
Yes Yes 73 389 705 1021 (Reserved) Common
Yes Yes 74 390 706 1022 (Reserved) Common
Yes Yes 75 391 707 1023 (Reserved) Common
Yes Yes 76 392 708 1024 (Reserved) Common
Yes Yes 77 393 709 1025 (Reserved) Common
Yes Yes 78 394 710 1026 (Reserved) Common
Yes Yes 79 395 711 1027 Bank 0: LSP ch
Yes Yes 80 396 712 1028 Bank 0: PID set No. ch
Allocated
to IN
Area
Allocated
to OUT
Area
Allocation number
(2-bytes decimal)
Item Attribute
Channel
1
Channel
2
Channel
3
Channel
4
