5 Communications Data for Modbus
5 - 6
E5C-T Digital Temperature Controllers Programmable Type Communications Manual (H186)
Note:The alarm function can also be used in Controllers without alarm output terminals. In this case, confirm alarm
occurrences via the status data.
*1 The set values for the program specified in the Program Selection parameter are accessed for the following parameters:
No. of Segments Used, Segment Selection, PID Set No., Alarm Values 1 to 4, Alarm Upper Limits 1 to 4, Alarm Lower
Limits 1 to 4, Program Repetitions, Program Link Destination No., Time Signal 1 and 2 Set Segments, Time Signal 1 and
2 ON Times, and Time Signal 1 and 2 OFF Times. Check the set value of the Program Selection parameter before
accessing these parameters.
182C 3816 Program 0 Time Signal 1
Set Segment
*1
Hí00000000 (0) to No. of segments used − 1
182E 3817 Program 0 Time Signal 1
ON Time
*1
H'00000000 to H'00009959 (0.00 to 99.59) (hours, minutes)
H'00000000 to H'00009959 (0.00 to 99.59) (minutes, seconds)
1830 3818 Program 0 Time Signal 1
OFF Time
*1
H'00000000 to H'00009959 (0.00 to 99.59) (hours, minutes)
H'00000000 to H'00009959 (0.00 to 99.59) (minutes, seconds)
1832 3819 Program 0 Time Signal 2
Set Segment
*1
Hí00000000 (0) to No. of segments used − 1Program
1834 381A Program 0 Time Signal 2
ON Time
*1
H'00000000 to H'00009959 (0.00 to 99.59) (hours, minutes)
H'00000000 to H'00009959 (0.00 to 99.59) (minutes, seconds)
1836 381B Program 0 Time Signal 2
OFF Time
*1
H'00000000 to H'00009959 (0.00 to 99.59) (hours, minutes)
H'00000000 to H'00009959 (0.00 to 99.59) (minutes, seconds)
Address
Parameter name Setting (monitor) value Level
Four-byte
mode
Two-byte
mode
To Next Page
