6 Programless Communications
6 - 50
E5C-T Digital Temperature Controllers Programmable Type Communications Manual (H186)
With the default settings, the following parameters are set for the download areas.
No.0 No.1 No.2 Parameter Value
D0025 D0095 D0165 Request Flag (fixed) 1 (0001 hex)
D0026 D0096 D0166 Operation Command Code (fixed) 0 (0000 hex)
D0027 D0097 D0167 Fixed SP 0 (0000 hex)
D0028 D0098 D0168 PID 1 Proportional Band 80 (0050 hex)
D0029 D0099 D0169 PID 1 Integral Time 233 (00E9 hex)
D0030 D0100 D0170 PID 1 Derivative Time 40 (0028 hex)
D0031 D0101 D0171 Program 0 Alarm Value 1 0 (0000 hex)
D0032 D0102 D0172 Program 0 Alarm Upper Limit 1 0 (0000 hex)
D0033 D0103 D0173 Program 0 Alarm Lower Limit 1 0 (0000 hex)
D0034 D0104 D0174 Program 0 Alarm Value 2 0 (0000 hex)
D0035 D0105 D0175 Program 0 Alarm Upper Limit 2 0 (0000 hex)
D0036 D0106 D0176 Program 0 Alarm Lower Limit 2 0 (0000 hex)
D0037 D0107 D0177 Heater Burnout Detection 1 0 (0000 hex)
D0038 D0108 D0178 Process Value Input Shift 0 (0000 hex)
D0039 D0109 D0179 Wait Band 0 (0000 hex)
D0040 D0110 D0180 Standby Time 0 (0000 hex)
D0041 D0111 D0181 Program SP Shift Value 0 (0000 hex)
D0042 D0112 D0182 Program 0 Segment 0 SP 0 (0000 hex)
D0043 D0113 D0183 Program 0 Segment 0 Time 0 (0000 hex)
D0044 D0114 D0184 Program 0 Segment 1 SP 0 (0000 hex)
D0045 D0115 D0185 Program 0 Segment 1 Time 0 (0000 hex)
D0046 D0116 D0186 Program 0 Segment 2 SP 0 (0000 hex)
D0047 D0117 D0187 Program 0 Segment 2 Time 0 (0000 hex)
D0048 D0118 D0188 Program 0 Segment 3 SP 0 (0000 hex)
D0049 D0119 D0189 Program 0 Segment 3 Time 0 (0000 hex)
D0050 D0120 D0190 Program 0 Segment 4 SP 0 (0000 hex)
D0051 D0121 D0191 Program 0 Segment 4 Time 0 (0000 hex)
D0052 D0122 D0192 Program 0 Segment 5 SP 0 (0000 hex)
D0053 D0123 D0193 Program 0 Segment 5 Time 0 (0000 hex)
D0054 D0124 D0194 Program 0 Segment 6 SP 0 (0000 hex)
D0055 D0125 D0195 Program 0 Segment 6 Time 0 (0000 hex)
D0056 D0126 D0196 Program 0 Segment 7 SP 0 (0000 hex)
D0057 D0127 D0197 Program 0 Segment 7 Time 0 (0000 hex)
D0058 D0128 D0198 Program 0 Segment 8 SP 0 (0000 hex)
D0059 D0129 D0199 Program 0 Segment 8 Time 0 (0000 hex)
D0060 D0130 D0200 Program 0 Segment 9 SP 0 (0000 hex)
D0061 D0131 D0201 Program 0 Segment 9 Time 0 (0000 hex)
· · · · · · · · · · · · · · ·
D0069 D0139 D0209 Not used.
