Omron E5CC-T

3 Communications Data for CompoWay/F
3 - 18
E5C-T Digital Temperature Controllers Programmable Type Communications Manual (H186)
C3 (83) 0089 Moving Average
Count
H'00000000 (0): OFF
H'00000001 (1): 2 times
H'00000002 (2): 4 times
H'00000003 (3): 8 times
H'00000004 (4): 16 times
H'00000005 (5): 32 times
Advanced
function
setting
C3 (83) 008A Alarm 4 Latch H'00000000 (0): OFF
H'00000001 (1): ON
C3 (83) 008B Alarm 4 ON delay H'00000000 to H'000003E7 (0 to 999)
C3 (83) 008C Alarm 4 OFF delay H'00000000 to H'000003E7 (0 to 999)
C3 (83) 008D Control Output 2
Signal
H'00000000 (0): 4 to 20 mA
H'00000001 (1): 0 to 20 mA
Initial
setting
C3 (83) 008E Transfer Output
Signal
H'00000000 (0): 4 to 20 mA
H'00000001 (1): 1 to 5 V
C3 (83) 008F Auxiliary Output 4
Assignment
H'00000000 to H'0000018 (0 to 24)
Note: Same as for the Auxiliary Output 1 Assignment
parameter.
Advanced
function
setting
C3 (83) 0091 Integral/Derivative
Time Unit
H'00000000 (0): 1 s
H'00000001 (1): 0.1 s
C3 (83) 0092 Manual Output
Method
H'00000000 (0): HOLD
H'00000001 (1): INIT
C3 (83) 0093 Manual MV Initial
Value
Standard control or close position-proportional control:
H'FFFFFFCE to H'0000041A (−5.0 to 105.0)
Heating and cooling control:
H'FFFFFBE6 to H'0000041A (−105.0 to 105.0)
C3 (83) 0094 Minimum Output
ON/OFF Band
H'00000000 to H'000001F4 (0.0 to 50.0)
C3 (83) 0095 Display Brightness H'00000001 to H'00000003 (1 to 3)
C3 (83) 0096 Highest
Communications
Unit No.
H'00000000 to H'00000063 (0 to 99) Communi
cations
setting
Variable
type
Address Parameter name Setting (monitor) value Level
