Omron E5CC-T

3 - 19
3 Communications Data for CompoWay/F
E5C-T Digital Temperature Controllers Programmable Type Communications Manual (H186)
3-1 Variable Area (Setting Range) List
3
C3 (83) 0097 Area H'00000000 (0: DM or D data registers)
H'00000001 (1: EM0 or W link registers)
H'00000002 (2: EM1 or R file registers)
H'00000003 (3: EM2 or ZR file registers)
H'00000004 (4: EM3)
H'00000005 (5: EM4)
H'00000006 (6: EM5)
H'00000007 (7: EM6)
H'00000008 (8: EM7)
H'00000009 (9: EM8)
H'0000000A (10: EM9)
H'0000000B (11: EMA)
H'0000000C (12: EMB)
H'0000000D (13: EMC)
H'0000000E (14: EMD)
H'0000000F (15: EME)
H'00000010 (16: EMF)
H'00000011 (17: EM10)
H'00000012 (18: EM11)
H'00000013 (19: EM12)
H'00000014 (20: EM13)
H'00000015 (21: EM14)
H'00000016 (22: EM15)
H'00000017 (23: EM16)
H'00000018 (24: EM17)
H'00000019 (25: EM18)
* Information after “or” is applicable when the Protocol
Setting parameter is set to MCP4.) Also, all set val-
ues of 4 and higher specify D data registers.
Communi
cations
setting
C3 (83) 0098 First Address
Upper Word
H'00000000 to H'00000063 (0 to 99)
C3 (83) 0099 First Address
Lower Word
H'00000000 to H'0000270F (0 to 9999)
C3 (83) 009A Receive Data Wait
Time
H'00000064 to H'0000270F (100 to 9999)
C3 (83) 009B Communications
Node Number
H'00000000 to H'00000063 (0 to 99)
C3 (83) 009C Upload Setting 1 H'00000000 to H'000000B3 (0 to 179)
C3 (83) 009D Upload Setting 2 H'00000000 to H'000000B3 (0 to 179)
C3 (83) 009E Upload Setting 3 H'00000000 to H'000000B3 (0 to 179)
C3 (83) 009F Upload Setting 4 H'00000000 to H'000000B3 (0 to 179)
C3 (83) 00A0 Upload Setting 5 H'00000000 to H'000000B3 (0 to 179)
C3 (83) 00A1 Upload Setting 6 H'00000000 to H'000000B3 (0 to 179)
C3 (83) 00A2 Upload Setting 7 H'00000000 to H'000000B3 (0 to 179)
C3 (83) 00A3 Upload Setting 8 H'00000000 to H'000000B3 (0 to 179)
C3 (83) 00A4 Upload Setting 9 H'00000000 to H'000000B3 (0 to 179)
C3 (83) 00A5 Upload Setting 10 H'00000000 to H'000000B3 (0 to 179)
C3 (83) 00A6 Upload Setting 11 H'00000000 to H'000000B3 (0 to 179)
C3 (83) 00A7 Upload Setting 12 H'00000000 to H'000000B3 (0 to 179)
C3 (83) 00A8 Upload Setting 13 H'00000000 to H'000000B3 (0 to 179)
C3 (83) 00A9 Download Setting
1
H'0000001E to H'000000B3 (30 to 179)
C3 (83) 00AA Download Setting
2
H'0000001E to H'000000B3 (30 to 179)
C3 (83) 00AB Download Setting
3
H'0000001E to H'000000B3 (30 to 179)
Variable
type
Address Parameter name Setting (monitor) value Level
