3.1 Variable Area (Setting Range) List
3-5
Note: The alarm function can also be used in Controllers without alarm output terminals. In this case,
confirm alarm occurrences via the status data.
C1 0019 Dead band H'FFFFF831 to H'0000270F
(−199.9 to 999.9 for TC/Pt multi-input models)
(−19.9 to 99.99 for Analog input models)
Adjust-
ment
C1 001A Manual reset value H'00000000 to H'000003E8 (0.0 to 100.0)
C1 001B Hysteresis (heating) H'00000001 to H'0000270F
(0.1 to 999.9 for TC/Pt multi-input models)
(0.01 to 99.99 for Analog input models)
C1 001C Hysteresis (cooling) H'00000001 to H'0000270F
(0.1 to 999.9 for TC/Pt multi-input models)
(0.01 to 99.99 for Analog input models)
C1 001D Heater burnout 2
detection
H'00000000 to H'000001F4 (0.0 to 50.0)
C1 001E HS alarm 1 H'00000000 to H'000001F4 (0.0 to 50.0)
C1 001F HS alarm 2 H'00000000 to H'000001F4 (0.0 to 50.0)
C1 0020 Soak time H'00000001 to H'0000270F (1 to 9999)
C1 0021 Wait band H'00000000 (0): OFF
H'00000001 to H'0000270F
(0.1 to 999.9 for TC/Pt multi-input models)
(0.01 to 99.99 for Analog input models)
C1 0022 MV at stop Standard: H'FFFFFFCE to H'0000041A (−5.0 to 105.0)
Heating and cooling: H'FFFFFBE6 to H'0000041A
(−105.0 to 105.0)
C1 0023 MV at PV error Standard: H'FFFFFFCE to H'0000041A (−5.0 to 105.0)
Heating and cooling: H'FFFFFBE6 to H'0000041A
(−105.0 to 105.0)
Vari-
able
type
Ad-
dress
Parameter name Setting (monitor) value Level
