SECTION 3 Communications Data for CompoWay/F and SYSWAY
3-6
Vari-
able
type
Ad-
dress
Parameter name Setting (monitor) value Level
C1 0024 Manual manipulated
variable
Standard: H'FFFFFFCE to H'0000041A (−5.0 to 105.0)
Heating and cooling: H'FFFFFBE6 to H'0000041A (−105.0
to 105.0)
Manual
Control
C1 0025 SP ramp set value H'00000000 (0): OFF
H'00000001 to H'0000270F (1 to 9999)
Adjust-
ment
C1 0026 MV upper limit Standard: MV lower limit + 0.1 to H’0000041A (MV lower
limit + 0.1 to 105.0)
Heating and cooling: H'00000000 to H'0000041A (0.0 to
105.0)
C1 0027 MV lower limit Standard: H’FFFFFFCE to MV upper limit − 0.1 (−5.0 to MV
upper limit − 0.1)
Heating and cooling: H'FFFFFBE6 to H'00000000 (−105.0
to 0.0)
C1 0028 Move protect level H'FFFFF831 to H'0000270F (−1999 to 9999) Protect
C1 0029 Password to move to
protect level
H'FFFFF831 to H'0000270F (−1999 to 9999)
(Can only be set. The monitor value is always H’00000000.)
C1 002A Parameter mask
enable
H'00000000 (0): OFF
H'00000001 (1): ON
C3 0000 Input type (TC/Pt
multi-input models)
(See note.)
H'00000000 (0): Pt (−200 to 850°C/−300 to 1500°F)
H'00000001 (1): Pt (−199.9 to 500.0°C/−199.9 to 900.0°F)
H'00000002 (2): Pt (0.0 to 100.0°C/0.0 to 210.0°F)
H'00000003 (3): JPt (−199.9 to 500.0°C/−199.9 to 900.0°F)
H'00000004 (4): JPt (0.0 to 100.0°C/0.0 to 210.0°F)
Initial set-
ting
H'00000005 (5): K (−200 to 1300°C/−300 to 2300°F)
H'00000006 (6): K (−20.0 to 500.0°C/0.0 to 900.0°F)
H'00000007 (7): J (−100 to 850°C/−100 to 1500°F)
H'00000008 (8): J (−20.0 to 400.0°C/0.0 to 750.0°F)
H'00000009 (9): T (−200 to 400°C/−300 to 700°F)
H'0000000A (10): T (−199.9 to 400.0°C/−199.9 to 700.0°F)
H'0000000B (11): E (0 to 600°C/0 to 1100°F)
H'0000000C (12): L (−100 to 850°C/−100 to 1500°F)
H'0000000D (13): U (−200 to 400°C/−300 to 700°F)
H'0000000E (14): U (−199.9 to 400.0°C/−199.9 to 700.0°F)
H'0000000F (15): N (−200 to 1300°C/−300 to 2300°F)
H'00000010 (16): R (0 to 1700°C/0 to 3000°F)
H'00000011 (17): S (0 to 1700°C/0 to 3000°F)
H'00000012 (18): B (100 to 1800°C/300 to 3200°F)
H'00000013 (19): Infrared temperature sensor
(K 140°F/60°C)
H'00000014 (20): Infrared temperature sensor
(K 240°F/120°C)
H'00000015 (21): Infrared temperature sensor
(K 280°F/140°C)
H'00000016 (22): Infrared temperature sensor
(K 440°F/220°C)
H'00000017 (23): 0 to 50 mV
