Omron E5GN Instructions

E5GN
E5GN
Initial Setting Level
Input type
Scaling upper limit
Decimal point
Temperature unit
Set point upper limit
PID / ON/OFF
Standard/heating and cooling
ST
Control period (heat)
Alarm 1 type
Move to advanced function
setting level
Set the pulse
output cycle.
Direct/reverse operation
Alarm 2 type
Limit the set point.
Select the control system.
Self-tuning
Select the alarm
mode.
Control period (cool)
For analog input
(Input type: 16)
0- to 50-mVsetting
Number of displayed digits
 : °C
 : °F
 : ON/OFF control
 : PID control
 : Standard
 : Heating/cooling
 : Enabled
 : Disabled
 : Reverse
 : Direct
Set point lower limit
Scaling lower limit
1
1
1
Note: 1. For E5CN only.
Adjustment Level
Hysteresis (heat)
AT execute/cancel
Communications writing
Heater current
value monitor
HBA
function
Set point 0
Set point 1
Temperature input shift
1-point shift
2-point shift
Proportional band
PID settings
Cooling coefficient
Dead band
Usedinheating and
cooling control
Manual reset value
Auto-tuning
Heater burnout
detection
Set point 2
Set point 3
Lower-limit temperature
input shift value
Upper-limit temperature
input shift value
Derivative time
Integral time
Clear the offset during
stabilization of P or PD
control.
Set hysteresis.
P
I
D
Hysteresis (cool)
 : Enabled
 : Disabled
2
2
2
2
2
multi-SP functions
are for E5CN only.
Note: 2. For E5CN only.

Omron E5GN Specifications

General

Brand	Omron
Model	E5GN
Category	Temperature Controller
Language	English
