Digital Temperature Controllers E5GN 1
Digital Temperature Controllers
E5GN
Compact and Intelligent Temperature
Controllers
1/32 DIN with Communications Function
• Various temperature inputs: Thermocouple, platinum resistance
thermometer, infrared temperature sensor, and analog inputs.
• Auto-tuning and self-tuning available. Auto-tuning is possible
even while self-tuning is being executed.
• Heating or heating/cooling control is available.
• Water-resistant construction (NEMA4X: equivalent to IP66).
• Conforms to UL, CSA, and IEC safety standards as well as CE
marking.
Refer to the “Safety Precautions” on page 16.
48(W) × 24(H) × 100(D) mm
Model Number Structure
■ Model Number Legend
1. Output type
R: Relay
Q: Voltage (for driving SSR)
2. Number of alarms
Blank: No alarm
1: One alarm
3. Communications
Blank: No communications function
03: RS-485
4. Input type
TC: Thermocouple
P: Platinum resistance thermometer
5. CompoWay/F serial communications
Blank: Not available
FLK: CompoWay/F serial communications
Ordering Information
■ Standard Models
Note 1. If the heating/cooling function is used, ALM1 will be used for control output and so alarm output will not be available.
2. Control output 2 for heating/cooling control is relay output.
3. Specify the power supply specifications when ordering.
12 34 5
E5GN- @ @ @ @ - @
Size Power supply
voltage
No. of alarm
points
Control output Thermocouple
model
Platinum resistance
thermometer model
1/32 DIN
48(W)
× 24(H) × 100(D) mm
100 to 240 VAC --- Relay E5GN-RTC E5GN-RP
Voltage (for driving
SSR)
E5GN-QTC E5GN-QP
1
(see note 1)
Relay E5GN-R1TC E5GN-R1P
Voltage (for driving
SSR)
E5GN-Q1TC E5GN-Q1P
24 VAC/VDC --- Relay E5GN-RTC E5GN-RP
Voltage (for driving
SSR)
E5GN-QTC E5GN-QP
1
(see note 1)
Relay E5GN-R1TC E5GN-R1P
Voltage (for driving
SSR)
E5GN-Q1TC E5GN-Q1P
