2 Digital Temperature Controllers E5GN
■ Communication Models
Note: Specify the power supply specifications when ordering.
Specifications
■ Ratings
Size Power supply
voltage
Communication
function
Control output Thermocouple model Platinum resistance
thermometer model
1/32 DIN
48(W)
× 24(H) × 100(D) mm
100 to 240 VAC RS-485 Relay E5GN-R03TC-FLK E5GN-R03P-FLK
Voltage (for driving
SSR)
E5GN-Q03TC-FLK E5GN-Q03P-FLK
24 VAC/VDC Relay E5GN-R03TC-FLK E5GN-R03P-FLK
Voltage (for driving
SSR)
E5GN-Q03TC-FLK E5GN-Q03P-FLK
Supply voltage 100 to 240 VAC, 50/60 Hz 24 VAC, 50/60 Hz/24 VDC
Operating voltage range 85% to 110% of rated supply voltage
Power consumption 7 VA 4 VA/2.5 W
Sensor input Thermocouple: K, J, T, E, L, U, N, R, S, B
Platinum resistance thermometer: Pt100, JPt100
Infrared temperature sensor: 10 to 70
°C, 60 to 120°C, 115 to 165°C, 140 to 260°C
Voltage input: 0 to 50 mV
Control output Relay output SPST-NO, 250 VAC, 2 A (resistive load), electrical life: 100,000 operations
Voltage output 12 VDC (PNP), max. load current: 21 mA, with short-circuit protection circuit
Alarm output SPST-NO, 250 VAC, 1 A (resistive load), electrical life: 100,000 operations
Control method 2-PID or ON/OFF control
Setting method Digital setting using front panel keys
Indication method 7-segment digital display and single-lighting indicator
Character height: PV: 7.0 mm; SV: 3.5 mm
Other functions Multi SP, SP ramp, MV limiter, input digital filter, self-tuning, input shift, run/stop, protection func-
tions, etc.
Ambient temperature
−10 to 55°C (with no condensation or icing)
Ambient humidity 25% to 85%
Storage temperature
−25 to 65°C (with no condensation or icing)

Omron E5GN Specifications

General

Brand	Omron
Model	E5GN
Category	Temperature Controller
Language	English
