Omron FH-L550 - FH-1000;2000;3000;5000 Series

Precautions for Correct Use
Turning OFF the Power
When a message is displayed indicating that a task is in progress, do not turn OFF the power
.
Doing so causes the data in the memory to be corrupted, resulting in the product not operating
properly upon the next start-up.
Do not turn OFF during saving data to Sensor Controller.
When turns OFF, conform the followings proceedings have completed. and then operate again.
- When saves using Sensor Controller: Confirm the save processing is completed and next op-
eration is possible.
- When saves using communication command: Intended command is completed. BUSY signal
is turned OFF.
Maintenance
Turn OFF the power and ensure the safety before maintenance.
5-1-2
FH-1000/2000/3000/5000 Series
Precautions for Safe Use
• Check the following again before turning on the power.
Are the voltage value and polarity of the power supply that is provided to the encoder cable
(ENC0 VDD/GND, ENC1 VDD/GND) correct? (5 VDC)
5 Setup and Wiring
5-3
FH Series Vision System Hardware Setup Manual (Z366-E1)
5-1 When turning ON and OFF
5
5-1-2 FH-1000/2000/3000/5000 Series
