Omron H7ET Series User Manual

H7ET
H7ET
8
Accessories
(
O
rder
S
eparately
)
An H7ET is supplied with a mounting bracket and nut. In addition, the panel-mounting adapters shown here allow the H7ET to be fitted to
existing panel cutouts.
J Y92F- 77B PANEL-MOUNTING ADAPTER
FOR 24.8 ¢ 48.8 RECTANGULAR CUTOUT
Must be used with mounting bracket supplied with the Counter
Panel cutout
J Y92F- 75 PANEL-MOUNTING ADAPTER
FOR 26 ¢ 45 RECTANGULAR CUTOUT
Must be used with mounting bracket supplied with the Counter
Panel cutout
28.8
(1.13)
24.2 22.2
45.2
48.2
53.8
(2.12)
4
24.8
(0.98)
48.8
(1.92)
31
(1.22)
24.2 22.2
45.2
48.2
Two 3.5 dia. mounting hol es
26
(1.02)
4
63
72
(2.83)
Two M3
45
63
(2.48)
26
Y92S-37 Wire-Wrap Terminal (Set of Two Terminals)
44.8
(1.76)
24
(0.94)
48
(1.89)
2
5
48.5
17.1
22
Wire-wrap terminal
(1 × 1 mm)
65.6
(2.58)
The wire-wrap terminals have a cross sectional dimension of
1x1 mm. Select one of three guages of wire from the table at
right. Also listed in the table is the appropriate wiring hardware.
Wire
Bit Sleeve Wrappe d
state
AWG22 2-A 2-B Normal
AWG24 1-A 1-B Normal
AWG26 1-B 1-B Normal
