9
2. Preparation
2.1 Installing/Replacing the Batteries
1. Turn the main unit upside down.
2. Slide the battery
cover in the direction
of the arrow while
pressing the ribbed
part of the cover.
3. Install or replace four
“AA” size batteries
so that the +
(positive) and -
(negative) polarities
match the polarities
indicated on the
battery
compartment.
4. Put the battery cover back in place.
Slide the battery cover as indicated, until it clicks into place.
Note: The measurement values continue to be stored in
memory even after the batteries are replaced.
