6. Apply the cuff to your left upper arm so the blue strip is on the inside
of your arm and aligned with your middle finger. The air tube runs
down the inside of your arm. The bottom of the cuff should be
approximately 1/2" above your elbow.
7. Wrap the cuff firmly in place around your arm using the cloth strip.
APPLYING THE ARM CUFF
1/2 inch (1 - 2 cm)
Air Tube
Blue Strip
