Omron JX Series User Manual

29
Multi-function input 1
selection
1103h C001 1401h C001
2nd multi-function input 1
selection
1532h C201
Multi-function input 2
selection
1104h C002 1402h C002
2nd multi-function input 2
selection
1533h C202
Multi-function input 3
selection
1105h C003 1403h C003
2nd multi-function input 3
selection
1534h C203
Multi-function input 4
selection
1106h C004 1404h C004
2nd multi-function input 4
selection
1535h C204
Multi-function input 5
selection
1107h C005 1405h C005
2nd multi-function input 5
selection
1536h C205
Multi-function input 1
110Bh C011 140Bh C011
Multi-function input 2
110Ch C012 140Ch C012
Multi-function input 3
110Dh C013 140Dh C013
Multi-function input 4
110Eh C014 140Eh C014
Multi-function input 5
110Fh C015 140Fh C015
00: FW
01: RV
02: CF1
03: CF2
04:CF3
05: CF4
06: JG
07: DB
08: SET
09: 2CH
11: FRS
12: EXT
13: USP
15: SFT
16: AT
18: RS
19: PTC terminal 5 only
20: STA
2+1: STP
22: F/R
23: PID
24: PIDC
27: UP
28: DWN
29: UDC
31: OPE
50: ADD
51: F-TM
52: RDY
53: SP-SET
64: EMR(automatically allocated to
terminal 3 if enabled)
255: NO
-
00: FW (Forward)
01: RV (Reverse)
02: CF1 (Multi-step speed setting
binary 1)
03: CF2 (Multi-step speed setting
binary 2)
04: CF3 (Multi-step speed setting
binary 3)
05: CF4 (Multi-step speed setting
binary 4)
06: JG (Jogging)
07: DB (External DC injection
braking)
08: SET (2nd control)
09: 2CH (2-step
acceleration/deceleration)
11: FRS (Free-run stop)
12: EXT (External trip)
13: USP (Power recovery restart
prevention function)
14: CS (Commercial switch)
15: SFT (Soft lock)
16: AT (Analog input switching)
18: RS (reset)
19: TH (PTC thermistor thermal
protection)
<C005 only>
20: STA (3-wire start)
21: STP (3-wire stop)
22: F/R (3-wire forward/reverse)
23: PID (PID disabled)
24: PIDC (PID integral reset)
27: UP (Remote operation
accelerated)
28: DWN (Remote operation
decelerated)
29: UDC (Remote operation data
clear)
31: OPE (Forced operator function)
32: SF1 (Multi-step speed setting bit
1)
33: SF2 (Multi-step speed setting bit
2)
34: SF3 (Multi-step speed setting bit
3)
35: SF4 (Multi-step speed setting bit
4)
36: SF5 (Multi-step speed setting bit
5)
37: SF6 (Multi-step speed setting bit
6)
38: SF7 (Multi-step speed setting bit
7)
39: OLR (Overload limit switching)
40: TL (Torque limit enabled)
41: TRQ1 (Torque limit switching 1)
42: TRQ2 (Torque limit switching 2)
44: BOK (Brake confirmation)
46: LAC (LAD cancel)
47: PCLR (Current position clear)
50: ADD (Set frequency A145
addition)
51: F-TM (Forced terminal block)
52: ATR (Torque reference input
permission)
53: KHC (Integrated power clear)
56: MI1 (General-purpose input 1)
57: MI2 (General-purpose input 2)
58: MI3 (General-purpose input 3)
-
00︓NO
01︓NC
-
00: NO (NO contact)
01: NC (NC contact)
-
