Omron LD

54
Cart
Description
Specification for Standard Platform
Physical
Length
592 mm
Width
846 mm
Height (body)
480 mm
Weight
23 kg (50 lb)
Rating
Caster ESD
ESD rated
Suspension
Passive Casters
2 front, 2 rear, spring-loaded rating
Caster Diameter
100 mm (4 in.) nominal
Caster Brakes
2 rear casters
9.3 Docking Station Specifications
Description
Specification
Current
8 A
Thermal fuse in AC power switch
(10 A Time-lag fuse at switch for legacy dock)
Contacts
2
Voltage
100 to 240 VAC, 50 to 60 Hz
Power consumption
800 W
Short circuit current rating
(SCCR)
1500 A
Humidity
5 to 95% non-condensing
Temperature
5° to 40° C (41° to 104° F)
Dimensions – WxDxH
with Floor plate
349 x 369 x 315 mm [13.75 x 14.5 x 12.4 in.]
495 x 495.5 x 317 mm [16 x 19.5 x 12.5 in.]
Weight
8.2 kg (18 lbs)
Mounting
Wall bracket, directly to floor, or on floor with floor plate
Indicators
Power on - blue
Charging - yellow
Connector
For out-of-platform battery charging
