8
1.Overview
Display
J. Systolic blood pressure
K. Diastolic blood pressure
L. Memory symbol
Displayed when viewing values
stored in memory
M. Battery low symbol
N. Heartbeat symbol
1. Flashes during measurement
2. If flashing after measurement
completed or when viewing
results stored in the memory,
indicates blood pressure out of
recommended range*
O. Pulse display
P. Deflation symbol
Q. Irregular heartbeat symbol
* Note: If your systolic or diastolic
pressure is outside the
standard range (above 135/
85 mmHg) the Heartbeat
symbol ( ) will blink.
Please refer to Chapter 3.3.6.
J
K
M
L
O
N
PQ
HEM-7102-IM_main.book Page 8 Friday, October 5, 2007 1:41 PM
