Omron MX2 Product Information

MX2 11
A Line filters A Input AC reactors
A DC reactors
A Chokes A Output AC reactor
B Accessories
Inverter
Line filter Rasmi
Voltage Model MX2-@ Reference
Rated current
(A)
1-Phase 200
VAC
AB001 / AB002 / AB004 AX-FIM1010-RE 10
AB007 AX-FIM1014-RE 14
AB015 / AB022 AX-FIM1024-RE 24
3-Phase 200
VAC
A2001 / A2002 /
A2004 / A2007
AX-FIM2010-RE 10
A2015 / A2022 AX-FIM2020-RE 20
A2037 AX-FIM2030-RE 30
A2055 / A2075 AX-FIM2060-RE 60
A2110 AX-FIM2080-RE 80
A2150 AX-FIM2100-RE 100
3-Phase 400
VAC
A4004 / A4007 AX-FIM3005-RE 5
A4015 / A4022 /
A4030
AX-FIM3010-RE 10
A4040 AX-FIM3014-RE 14
A4055 / A4075 AX-FIM3030-RE 23
A4110 / A4150 AX-FIM3050-RE 50
Inverter
AC Reactor
Voltage Model MX2-@ Reference
3-Phase 200 VAC
A2002 / A2004 / A2007 AX-RAI02800080-DE
A2015 / A2022 / A2037 AX-RAI00880200-DE
A2055 / A2075 AX-RAI00350335-DE
A2110 / A2150 AX-RAI00180670-DE
1-Phase 200 VAC
AB002 / AB004
Under developmentAB007
AB015 / AB022
3-Phase 400 VAC
A4004 / A4007 / A4015 AX-RAI07700050-DE
A4022 / A4030 / A4040 AX-RAI03500100-DE
A4055 / A4075 AX-RAI01300170-DE
A4110 / A4150 AX-RAI00740335-DE
200V single phase
200V 3-phase 400V 3-phase
Inverter
DC Reactor
Inverter
DC Reactor
Inverter
DC Reactor
MX2-AB001
AX-RC10700032-DE
MX2-A2001
AX-RC21400016-DE
MX2-A4004 AX-RC43000020-DE
MX2-AB002 MX2-A2002 MX2-A4007 AX-RC27000030-DE
MX2-AB004 AX-RC06750061-DE MX2-A2004 AX-RC10700032-DE MX2-A4015 AX-RC14000047-DE
MX2-AB007 AX-RC03510093-DE MX2-A2007 AX-RC06750061-DE MX2-A4022 AX-RC10100069-DE
MX2-AB015 AX-RC02510138-DE MX2-A2015 AX-RC03510093-DE MX2-A4030 AX-RC08250093-DE
MX2-AB022 AX-RC01600223-DE MX2-A2022 AX-RC02510138-DE MX2-A4040 AX-RC06400116-DE
-
MX2-A2037 AX-RC01600223-DE MX2-A4055 AX-RC04410167-DE
MX2-A2055 AX-RC01110309-DE MX2-A4075 AX-RC03350219-DE
MX2-A2075 AX-RC00840437-DE MX2-A4011 AX-RC02330307-DE
MX2-A2011 AX-RC00590614-DE MX2-A4015 AX-RC01750430-DE
MX2-A2015 AX-RC00440859-DE -
Model Diameter Description
AX-FER2102-RE 21 For 2.2 KW motors or below
AX-FER2515-RE 25 For 15 KW motors or below
AX-FER5045-RE 50 For 45 KW motors or below
Inverter
AC Reactor
Voltage Model MX2-@ Reference
200 VAC
A2001 / A2002 / A2004
AB001 / AB002 / AB004
AX-RAO11500026-DE
A2007/AB007 AX-RAO07600042-DE
A2015 / AB015 AX-RAO04100075-DE
A2022 / AB022 AX-RAO03000105-DE
A2037 AX-RAO01830160-DE
A2055 AX-RAO01150220-DE
A2075 AX-RAO00950320-DE
400 VAC
A4004 / A4007 / A4015 AX-RAO16300038-DE
A4022 AX-RAO11800053-DE
A4030 / A4040 AX-RAO07300080-DE
A4055 AX-RAO04600110-DE
A4075 AX-RAO03600160-DE
Types Model Description Functions
Digital
operator
AX-OP05-E LCD remote operator 5 Line LCD remote operator with copy function, cable length max. 3m.
3G3AX-CAJOP300-EE Remote operator cable 3 meters cable for connecting remote operator
3G3AX-OP01 LED remote operator LED remote operator, cable length max. 3m
4X-KITMINI Mounting kit for LED operator Mounting kit for LED operator on panel
Accessories
AX-CUSBM002-E PC configuration cable Mini USB to USB connector cable

Omron MX2 Specifications

General

Model	MX2
Category	Inverter
Enclosure Rating	IP20
Control Method	V/f control, Sensorless vector control
Frequency Range	0.1 to 400 Hz
Protection	Overcurrent, Overvoltage, Undervoltage, Overheat, Short circuit
Communication	Modbus RTU
Ambient Temperature	-10 to 50 °C (without freezing or condensation)
Overload Capacity	150% for 60 seconds
Cooling Method	Fan Cooled
Humidity	5 to 95% RH (without condensation)
Altitude	Up to 1000m without derating
Voltage	200-240 VAC, 380-480 VAC
Braking Unit	Built-in (for certain models), Optional External
