4-4 Creating Screens
4
4
NP Introduction Manual 79
Creating Screens
1. Select [Objects] - [Button] - [Alternative] from the main menu. Move the
mouse cursor to the workspace.
The cursor will change shape to [+].
2. Move the cursor.
A button frame will show.
3. Set button properties.
●Function Switches
Set the function switches.
For details, refer to [01 Waiting]. Setting details are the same.
The [05 Fully Open] screen is now complete.
Item Setting
Write Address SERIALA:WR0.01
Read Address SERIALA:WR0.01
Label Deactivate [line break] Auto-close
Label Size 12
