Omron NP3 Series

4-4 Creating Screens
4
4
NP Introduction Manual 81
Creating Screens
●Fixed Object (Text)
Create the "Sensor Check" and "Vehicle Sensor" text objects.
For details, refer to [01 Waiting].
Use these settings.
Sensor Check
* Select [Bold] and [Center] from the toolbar.
Vehicle Sensor
* Select [Bold] and [Center] from the toolbar.
●Lamp (N-State)
1. Select [Objects] - [Lamp] - [N-State Lamp] from the main menu. Move the
mouse cursor to the workspace.
The cursor will change shape to [+].
2. Move the cursor.
A lamp frame will show.
3. Set lamp properties.
4. Click .
You will see the lamp of the ON status.
5. Set lamp properties.
●Button (Change Screen)
This button is used to switch to the [01 Waiting] screen.
1. Select [Objects] - [Button] - [Change Screen] from the main menu. Move
the mouse cursor to the workspace.
The cursor will change shape to [+].
Item Setting
Label Sensor Check*
Label Size 24
Label Color (Black)RGB(16,16,16)
Foreground Color (White)RGB(255,255,255)
Item Setting
Label Vehicle Sensor*
Label Size 16
Label Color (Black)RGB(16,16,16)
Foreground Color (White)RGB(255,255,255)
Item Setting
Read Address SERIALA:0.03
Style Round
Item Setting
Foreground Color (Black)RGB(16,16,16)
