Omron NP3 Series

4-4 Creating Screens
4
4
NP Introduction Manual 83
Creating Screens
4. Move the copied objects to adjust their position.
5. Repeat steps 2 to 4 to create the remaining objects.
6. Change the properties of the copied objects.
Change the properties as below.
a
b
c
Object Item Setting
Fixed Object (Text) Label Light Sensor
Lamp (N-state) Read Address SERIALA:00000.04
Object Item Setting
Fixed Object (Text) Label Upper LS
Lamp (N-state) Read Address SERIALA:00000.05
Object Item Setting
Fixed Object (Text) Label Lower LS
Lamp (N-state) Read Address SERIALA:00000.06
