Appendix 8 Standard Models
CPU Units That Connect in 1:N NT Links via RS-232C to PT Serial Ports
PLC Series Connecting with built-in ports Connecting via optional
Communications Boards
CS Series CS1G-CPU42(-V1)
CS1G-CPU43(-V1)
CS1G-CPU44(-V1)
CS1G-CPU45(-V1)
CS1H-CPU63(-V1)
CS1H-CPU64(-V1)
CS1H-CPU65(-V1)
CS1H-CPU66(-V1)
CS1H-CPU67(-V1)
CS1G-CPU42H
CS1G-CPU43H
CS1G-CPU44H
CS1G-CPU45H
CS1H-CPU63H
CS1H-CPU64H
CS1H-CPU65H
CS1H-CPU66H
CS1H-CPU67H
CS1D-CPU65H
CS1D-CPU67H
Same as at left (see note 1).
CJ Series CJ1G-CPU42H (See note 2.)
CJ1G-CPU43H (See note 2.)
CJ1G-CPU44H (See note 2.)
CJ1G-CPU45H (See note 2.)
CJ1M-CPU11
CJ1M-CPU12
CJ1M-CPU13
CJ1M-CPU21
CJ1M-CPU22
CJ1M-CPU23
CJ1H-CPU65H (See note 2.)
CJ1H-CPU66H (See note 2.)
Same as at left (see note 2).
C200HE-CPU42(-Z) C200HE-CPU32(-Z) (See note 3.)
C200HE-CPU42(-Z) (See note 3.)
C200HG-CPU43(-Z)
C200HG-CPU63(-Z)
C200HG-CPU33(-Z) (See note 3.)
C200HG-CPU43(-Z) (See note 3.)
C200HG-CPU53(-Z) (See note 3.)
C200HG-CPU63(-Z) (See note 3.)
C200HX-CPU44(-Z)
C200HX-CPU64(-Z)
C200HX-CPU65-Z
C200HX-CPU85-Z
C200HX-CPU34(-Z) (See note 3.)
C200HX-CPU44(-Z) (See note 3.)
C200HX-CPU54(-Z) (See note 3.)
C200HX-CPU64(-Z) (See note 3.)
C200HX-CPU65-Z (See note 3.)
C200HX-CPU85-Z (See note 3.)
C Series
--- CQM1H-CPU21 (See note 4.)
CQM1H-CPU51 (See note 4.)
CQM1H-CPU61 (See note 4.)
Note 1. A CS1W-SCB21/SCB41 Serial Communications Board or a CS1W-SCU21 Serial Com-
munications Unit is required.
2. A CJ1W-SCU41 Serial Communications Unit is required.
3. A C200HW-COM02/COM04/COM05/COM06(-V1) Communications Board is required.
4. A CQM1H-SCB41 Serial Communications Board is required.
Reference NS-series RS-485 (two-wire) communications are used to connect to an OMRON
Temperature Controller. The NS-AL002 cannot be used with the NT-series PTs or
PLCs. Connect using RS-422A (4-wire).
