The following table describes the items in the Property Dialog Box.
Item Editing Description
Name Possible This is the name that is currently set for the POU.
CRC Not possible This is the CRC data of the POU.
You can also check the CRC data on the Change Tracking Tab Page.
Version Possible This is the version information for the POU.
You can also check the version information on the Change T
racking Tab Page.
Author Possible This is the person that created the POU.
Created Not possible This is the date that the POU was created.
Updated Not possible This is the date that the POU was updated.
Comment Possible This is a comment for the POU.
Precautions for Correct Use
The author, creation date, and update date cannot be saved on Sysmac Studio version 1.12 or
lower.
If you open a project on Sysmac Studio version 1.12 or lower
, this data will be lost.
Version Information
Sysmac Studio version 1.13 or higher is required to display these properties.
Exporting Programs
You can export a program to a file (extension .spg).
You can import an exported program to reuse it in another project.
Use the following procedure.
1 Right-click a program displayed under Programming -
POUs - Programs in the Multiview Ex-
plorer, and then select Export
from the menu.
The Export Dialog Box is displayed.
6 Programming
6 - 29
NX-series Safety Control Unit User's Manual (Z930)
6-5 Programming Operations
6
6-5-2 Registering POUs
To Next Page
