2 Enter a file name, and then click the Save Button.
A program file with an .spg extension is saved.
Precautions for Correct Use
• Do not delete the program CRC data that is displayed after the program is exported. It is
used to check the data when importing the program.
You can check the CRC data on the Change T
racking Tab Page or Properties Dialog Box.
• The spg program file includes information on global variables that are used as external varia-
bles.
Version Information
You can export programs with Sysmac Studio version 1.17 or higher.
Importing Programs
You can import an exported program to reuse it in another project.
WARNING
Check during the import of the program that the CRC of the program is
correct. Serious injury may possibly occur due to loss of required safety
functions.
Use the following procedure to import a program that was previously exported.
1 Right-click Programs under Programming - POUs in the Multiview Explorer and select
Import from the menu.
The Import Dialog Box is displayed.
6 Programming
6 - 30
NX-series Safety Control Unit User's Manual (Z930)
