(Example) For Ver.1.0, 0100££££ hex
*2. The unique serial number of the product is given.
Bits 0 to 31: Serial number
*3. The date of manufacture is given for the "lot number".
Bits 24 to 31: Day of manufacture
Bits 16 to 23: Month of manufacture
Bits 8 to 15: Year of manufacture
Bits 0 to 7: Reserved
*4.
The hardware version is given in order in the lowest elements of the array. Unused elements are padded with spaces.
*5. The software version is given in order in the lowest elements of the array. Unused elements are padded with spaces.
Objects That Accept I/O Allocations
These objects accept I/O allocations.
They cannot be accessed through message communications.
Index
(hex)
Subindex
(hex)
Object name Default value Data range Unit Data type
Ac-
cess
I/O
allo-
cati-
on
Data
at-
trib-
ute
6000 --- FSoE Slave Frame
Elements
--- --- --- --- --- --- ---
00 Number of Entries 3 3 --- USINT RO Not
sup-
port-
ed
---
01 FSoE Slave CMD 00 hex 00 to FF hex --- BYTE RO Sup-
port-
ed
---
02 FSoE Slave
Conn_ID
0000 hex 0000 to FFFF
hex
--- WORD RO Sup-
port-
ed
---
03 FSoE Slave
CRC_0
0000 hex 0000 to FFFF
hex
--- WORD RO Sup-
port-
ed
---
Index
(hex)
Subindex
(hex)
Object name Default value Data range Unit Data type
Ac-
cess
I/O
allo-
cati-
on
Data
at-
trib-
ute
6001 --- Safety Input Data --- --- --- --- --- --- ---
00 Number of Entries 1 1 --- USINT RO Not
sup-
port-
ed
---
01 Safety Input 1st
Byte
0000 hex 0000 to FFFF
hex
--- WORD RO Sup-
port-
ed
---
Appendices
A - 13
NX-series Safety Control Unit User's Manual (Z930)
A-2 NX Objects
A
A-2-4 NX-SID800 Safety Input Unit
