Index
(hex)
Subindex
(hex)
Object name Default value Data range Unit Data type
Ac-
cess
I/O
allo-
cati-
on
Data
at-
trib-
ute
6002 --- Standard Input Da-
ta
--- --- --- --- --- --- ---
00 Number of Entries 2 2 --- USINT RO Not
sup-
port-
ed
---
01 Standard Input 1st
W
ord
0000 hex
0000 to FFFF
hex
*1
--- WORD RO Sup-
port-
ed
---
02 Standard Input 2nd
Byte
00 hex
00 to FF hex
*2
--- BYTE RO Sup-
port-
ed
---
*1. The details of the "Standard Input 1st Word" are as follows:
Bit 0: Si00 Logical Value
Bit 1: Si01 Logical V
alue
Bit 2: Si02 Logical Value
Bit 3: Si03 Logical Value
Bit 4: Si04 Logical Value
Bit 5: Si05 Logical Value
Bit 6: Si06 Logical Value
Bit 7: Si07 Logical Value
Bit 8: Safety Connection Status
Bit 9: Safety Input Terminal Status
Bit 10: Unit Normal Status
Bit 11: IO Power Supply Error Flag
Bits 12 to 15: Reserved
*2. The details of the "Standard Input 2nd Byte" are as follows:
Bit 0: Si00 Status
Bit 1: Si01 Status
Bit 2: Si02 Status
Bit 3: Si03 Status
Bit 4: Si04 Status
Bit 5: Si05 Status
Bit 6: Si06 Status
Bit 7: Si07 Status
Appendices
A - 14
NX-series Safety Control Unit User's Manual (Z930)
