Index
(hex)
Subindex
(hex)
Object name Default value Data range Unit Data type
Ac-
cess
I/O
allo-
cati-
on
Data
at-
trib-
ute
7000 --- FSoE Master
Frame Elements
--- --- --- --- --- --- ---
00 Number of Entries 3 3 --- USINT RO Not
sup-
port-
ed
---
01 FSoE Master CMD 00 hex 00 to FF hex --- BYTE RW Sup-
port-
ed
---
02 FSoE Master
Conn_ID
0000 hex 0000 to FFFF
hex
--- WORD RW Sup-
port-
ed
---
03 FSoE Master
CRC_0
0000 hex 0000 to FFFF
hex
--- WORD RW Sup-
port-
ed
---
Index
(hex)
Subindex
(hex)
Object name Default value Data range Unit Data type
Ac-
cess
I/O
allo-
cati-
on
Data
at-
trib-
ute
7001 --- Safety Output Data --- --- --- --- --- --- ---
00 Number of Entries 1 1 --- USINT RO Not
sup-
port-
ed
---
01 Safety Output 1st
W
ord
0000 hex
0000 to FFFF
hex
--- WORD RW Sup-
port-
ed
---
Index
(hex)
Subindex
(hex)
Object name Default value Data range Unit Data type
Ac-
cess
I/O
allo-
cati-
on
Data
at-
trib-
ute
7002 --- Standard Output
Data
--- --- --- --- --- --- ---
00 Number of Entries 2 2 --- USINT RO Not
sup-
port-
ed
---
01 Standard Output
1st W
ord
0000 hex
0000 hex
*1
---
WORD RW Sup-
port-
ed
---
02 Standard Output
2nd Byte
00 hex
00 hex
*2
--- BYTE RW Sup-
port-
ed
---
*1. "Standard Output 1st Word" is reserved by the system.
*2. "Standard Output 2nd Byte" is reserved by the system.
Appendices
A - 15
NX-series Safety Control Unit User's Manual (Z930)
A-2 NX Objects
A
A-2-4 NX-SID800 Safety Input Unit
