Index
(hex)
Subindex
(hex)
Object name Default value Data range Unit Data type
Ac-
cess
I/O
allo-
cati-
on
Data
at-
trib-
ute
6002 --- Standard Input Da-
ta
--- --- --- --- --- --- ---
00 Number of Entries 2 2 --- USINT RO Not
sup-
port-
ed
---
01 Standard Input 1st
Byte
00 hex
00 to FF hex
*1
--- BYTE RO Sup-
port-
ed
---
02 Standard Input 2nd
Byte
00 hex
00 to FF hex
*2
--- BYTE RO Sup-
port-
ed
---
*1. The details of the "Standard Input 1st Byte" are as follows:
Bit 0: So00 Monitor Value
Bit 1: So01 Monitor V
alue
Bit 2: Safety Connection Status
Bit 3: Safety Output Terminal Status
Bit 4: Unit Normal Status
Bit 5: IO Power Supply Error Flag
Bits 6 to 7: Reserved
*2. The details of the "Standard Input 2nd Byte" are as follows:
Bit 0: So00 Status
Bit 1: So01 Status
Bits 2 to 7: Reserved
Index
(hex)
Subindex
(hex)
Object name Default value Data range Unit Data type
Ac-
cess
I/O
allo-
cati-
on
Data
at-
trib-
ute
7000 --- FSoE Master
Frame Elements
--- --- --- --- --- --- ---
00 Number of Entries 3 3 --- USINT RO Not
sup-
port-
ed
---
01 FSoE Master CMD 00 hex 00 to FF hex --- BYTE RW Sup-
port-
ed
---
02 FSoE Master
Conn_ID
0000 hex 0000 to FFFF
hex
--- WORD RW Sup-
port-
ed
---
03 FSoE Master
CRC_0
0000 hex 0000 to FFFF
hex
--- WORD RW Sup-
port-
ed
---
