Variable name Meaning Function Data type
Range of
values
Reference
_EIP1_TargetPLC-
ModeSta[255]
CIP Communica-
tions1 T
arget PLC
Operating Mode
Shows the operating status of the target
node Controllers that are connected for
CIP communications 1 with the built-in
EtherNet/IP port as the originator.
The array elements are valid only when
the corresponding Normal Target Node
Information is TRUE. If the corresponding
Normal Target Node Information is
FALSE, it indicates the previous operat-
ing status.
Array[x] is TRUE:
This is the operating state of the target
Controller with a node address of x.
Array[x] is FALSE:
Other than the above.
Note You can use this system-de-
fined variable only for NX-ser-
ies CPU Units.
ARRAY
[0..255] OF
BOOL
TRUE or
FALSE
page 3-56
_EIP2_TargetPLC-
ModeSta[255]
CIP Communica-
tions2 T
arget PLC
Operating Mode
Shows the operating status of the target
node Controllers that are connected for
CIP communications 2 with the built-in
EtherNet/IP port as the originator.
The array elements are valid only when
the corresponding Normal Target Node
Information is TRUE. If the corresponding
Normal Target Node Information is
FALSE, it indicates the previous operat-
ing status.
Array[x] is TRUE:
This is the operating state of the target
Controller with a node address of x.
Array[x] is FALSE:
Other than the above.
Note You can use this system-de-
fined variable only for the
NX701 CPU Units and NX102
CPU Units.
ARRAY
[0..255] OF
BOOL
TRUE or
FALSE
page 3-56
3 System-defined Variables Related to the Built-in EtherNet/IP Port
3-27
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
3-2 System-defined Variables
3
