16-2-2
Connection Status Codes and Troubleshooting
This section explains how to identify and correct errors based on the tag data link's connection status.
The connection status can be read using the Connection T
ab Page of the Network Configurator’s Mon-
itor Device Window. Refer to 16-2-1 The Network Configurator's Device Monitor Function on page
16-3.
Additional Information
The connection status has the same meaning as the Connection Manager's General and Addi-
tional error response codes, as defined in the CIP specifications.
The following table shows the likely causes of the errors causes for each configuration and connection
status (code).
Originator Target
Configuration 1
CS1W-EIP21, CJ1W-EIP21, CJ2H-CPU££-EIP
,
CJ2M-CPU3£, NJ501-££££, NJ301-££££,
NJ101-££££, NX701-££££, NX102-££££,
NX1P2-££££££
CS1W-EIP21, CJ1W-EIP21, CJ2H-CPU££-EIP
,
CJ2M-CPU3£, NJ501-££££, NJ301-££££,
NJ101-££££, NX701-££££, NX102-££££,
NX1P2-££££££
Configuration 2
CS1W-EIP21, CJ1W-EIP21, CJ2H-CPU££-EIP
,
CJ2M-CPU3£, NJ501-££££, NJ301-££££,
NJ101-££££, NX701-££££, NX102-££££,
NX1P2-££££££
Products from other manufacturers
Configuration 3 Products from other manufacturers
CS1W-EIP21, CJ1W-EIP21, CJ2H-CPU££-EIP
,
CJ2M-CPU3£, NJ501-££££, NJ301-££££,
NJ101-££££, NX701-££££, NX102-££££,
NX1P2-££££££
Connection status
Source of error
Handling
General
Status
(hex)
Additional
Status
(hex)
Configuration
1
Configuration
2
Configuration
3
00 0000 Normal status code:
The connection has been opened and
the tag data link is communicating nor-
mally
.
--- --- ---
01 0100 Error code returned from target:
Attempted to open multiple connections
for the same connection.
This error does
not occur
.
Depends on
the target's
specifications.
(This error
should not oc-
cur. If it does,
contact the tar-
get device's
manufacturer.)
Depends on
the originator's
specifications.
(This error
should not oc-
cur. If it does,
contact the
originator devi-
ce's manufac-
turer.)
01 0103 Error code returned from target:
Attempted to open a connection with an
unsupported transport class.
This error does
not occur
.
Confirm that
the target sup-
ports Class 1.
Confirm that
the originator
supports Class
1.
16 Troubleshooting
16-11
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
16-2 Checking Status with the Network Configurator
16
16-2-2 Connection Status Codes and Troubleshooting
