Select the check boxes of the networks to save and click the
OK
Button.
7-2-15
Reading a Network Configuration File
Y
ou can read out a previously saved network configuration file into the Network Configurator
.
1
Select
File
-
Open
, or click the
Button.
The following dialog box is displayed.
7 T
ag Data Link Functions
7-74
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User
’
s Manual (W506)
