Variable name _EIP_TargetPLCErr[255]
Meaning Target PLC Error Information Global/local Global
Function NX-series CPU Units: Shows the error status (logical OR of fatal and non-fatal errors) of the target node Control-
lers that are connected for CIP communications 1, with the built-in EtherNet/IP ports as the originator
. The array
elements are valid only when the corresponding Normal Target Node Information is TRUE. The immediately pre-
ceding value is retained if this variable is FALSE.
Array[x] is TRUE: A fatal or non-fatal error occurred in the target Controller with a target node ID of x.
Array[x] is FALSE: Other than the above.
NJ-series CPU Units: Shows the error status (logical OR of fatal and non-fatal errors) of the target node Control-
lers that are connected with the built-in EtherNet/IP ports as the originator. The array elements are valid only
when the corresponding Normal Target Node Information is TRUE. The immediately preceding value is retained if
this variable is FALSE.
Array[x] is TRUE: A fatal or non-fatal error occurred in the target Controller with a target node ID of x.
Array[x] is FALSE: Other than the above.
Data type ARRAY [0..255] OF BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Published.
Usage in user pro-
gram
Possible. Related in-
structions
---
Variable name _EIP1_TargetPLCErr[255]
Meaning CIP Communications1 Target PLC Error Infor-
mation
Global/local Global
Function Shows the error status (logical OR of fatal and non-fatal errors) of the target node Controllers that are connected
for CIP communications 1, with the built-in EtherNet/IP ports as the originator
. The array elements are valid only
when the corresponding Normal Target Node Information is TRUE. The immediately preceding value is retained if
this variable is FALSE.
Array[x] is TRUE: A fatal or non-fatal error occurred in the target Controller with a target node ID of x.
Array[x] is FALSE: Other than the above.
Note You can use this system-defined variable only for NX-series CPU Units.
Data type ARRAY [0..255] OF BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Published.
Usage in user pro-
gram
Possible. Related in-
structions
---
Variable name _EIP2_TargetPLCErr[255]
Meaning CIP Communications2 Target PLC Error Infor-
mation
Global/local Global
Function Shows the error status (logical OR of fatal and non-fatal errors) of the target node Controllers that are connected
for CIP communications 2, with the built-in EtherNet/IP ports as the originator
. The array elements are valid only
when the corresponding Normal Target Node Information is TRUE. The immediately preceding value is retained if
this variable is FALSE.
Array[x] is TRUE: A fatal or non-fatal error occurred in the target Controller with a target node ID of x.
Array[x] is FALSE: Other than the above.
Note You can use this system-defined variable only for the NX701 CPU Units and NX102 CPU Units.
Data type ARRAY [0..255] OF BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Published.
Usage in user pro-
gram
Possible. Related in-
structions
---
3 System-defined Variables Related to the Built-in EtherNet/IP Port
3-57
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
3-3 Specifications for Individual System-defined Varia-
