Icon Status
(white)
Offline
(gray)
Default (including no Controller Configurations and Setup)
(green)
Idle (including when the Controller is in PROGRAM mode)
(blue)
Normal communications state (including when the Controller is in RUN mode)
(yellow)
Warning status (including when there is a partial fault or non-fatal error in the Con-
troller)
(red)
Alarm status (including when there is a major fault or fatal error in the Controller)
7 Tag Data Link Functions
7-79
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
7-2 Setting Tag Data Links
7
7-2-18 Displaying Device Status
