Omron NX701-1720 User Manual

Level 1 Level 2 Level 3
Variable Name Variable Name Variable Name
_EIP_ErrSta Built-in Ether-
Net/IP Error
_EIP1_Po
rtErr
Communi-
cations
Port1 Er-
ror
_EIP1_MacAdrErr Port1 MAC Address Error
_EIP1_LanHwErr Port1 Communications Controller
Error
_EIP1_EtnCfgErr Port1 Basic Ethernet Setting Error
_EIP1_IPAdrCfgErr Port1 IP Address Setting Error
_EIP1_IPAdrDupErr Port1 IP Address Duplication Error
_EIP1_BootpErr Port1 BOOTP Server Error
_EIP_DNSCfgErr DNS Setting Error
_EIP_DNSSrvErr DNS Server Connection Error
_EIP_IPRTblErr IP Route Table Error
_EIP2_Po
rtErr
Communi-
cations
Port2 Er-
ror
_EIP2_MacAdrErr Port2 MAC Address Error
_EIP2_LanHwErr Port2 Communications Controller
Error
_EIP2_EtnCfgErr Port2 Basic Ethernet Setting Error
_EIP2_IPAdrCfgErr Port2 IP Address Setting Error
_EIP2_IPAdrDupErr Port2 IP Address Duplication Error
_EIP2_BootpErr Port2 BOOTP Server Error
_EIP_DNSCfgErr DNS Setting Error
_EIP_DNSSrvErr DNS Server Connection Error
_EIP_IPRTblErr IP Route Table Error
_EIP1_Ci-
pErr
CIP Com-
munica-
tions1 Er-
ror
_EIP1_IdentityErr CIP Communications1 Identity Error
_EIP1_TDLinkCfgErr CIP Communications1 Tag Data
Link Setting Error
_EIP1_TDLinkOpnErr CIP Communications1 Tag Data
Link Connection Failed
_EIP1_TDLinkErr CIP Communications1 Tag Data
Link Communications Error
_EIP1_TagAdrErr CIP Communications1 Tag Name
Resolution Error
_EIP1_MultiSwONErr CIP Communications1 Multiple
Switches ON Error
_EIP2_Ci-
pErr
CIP Com-
munica-
tions2 Er-
ror
_EIP2_IdentityErr CIP Communications2 Identity Error
_EIP2_TDLinkCfgErr CIP Communications2 Tag Data
Link Setting Error
_EIP2_TDLinkOpnErr CIP Communications2 Tag Data
Link Connection Failed
_EIP2_TDLinkErr CIP Communications2 Tag Data
Link Communications Error
_EIP2_TagAdrErr CIP Communications2 Tag Name
Resolution Error
_EIP2_MultiSwONErr CIP Communications2 Multiple
Switches ON Error
_EIP_Tcp
AppErr
TCP Ap-
plication
Communi-
cations
Error
_EIP_TcpAppCfgErr TCP Application Setting Error
_EIP_NTPSrvErr NTP Server Connection Error
Note 1. You can access the same values of the system-defined variables whose variable names with _EIP1
and the system-defined variables whose variable names with _EIP. For example, you can access the
same values of _EIP1_PortErr (Communications Port1 Error) and _EIP_PortErr (Communications
Port Error).
Note 2. You can use the system-defined variables whose variable names with _EIP2 only for the NX701 CPU
Units and NX102 CPU Units.
3 System-defined Variables Related to the Built-in EtherNet/IP Port
3-20
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
